PUMA V400MR
- Exceptional Stability and Rigidity: Both models feature robust construction with integral box guideways and reinforced bed frames, ensuring high stability and precision in heavy-duty machining.
- Enhanced Productivity: The PUMA V8300/9300 Series offers the largest turning capacity in its class, significantly boosting productivity and profitability.
- Compact Efficiency: The PUMA V400's compact footprint allows for efficient space utilization without compromising on performance and accuracy.
Highlights
- Travels - X Axis Travel distance (mm): 268
- Travels - Z Axis Travel distance (mm): 488
- Chuck size (mm): 305
- Max. Turning Diameter (mm): 420
- Max. Turning Length (mm): 400
Series description
The PUMA V400 and PUMA V8300/9300 Series are high-performance vertical turning centers designed for heavy-duty machining. The compact PUMA V400 offers powerful spindle drives, Meehanite casting, and integral box guideway construction for exceptional stability and accuracy. The PUMA V8300/9300 Series, with 15" to 32" chuck sizes, features a column-integrated box guideway and reinforced bed frame, providing robust structure and the largest turning capacity in its class for enhanced productivity and profitability. |
Specifications
Travels
Travels - X Axis Travel distance (mm) | 268 |
---|---|
Travels - Z Axis Travel distance (mm) | 488 |
Travels - X Axis Rapid Traverse (m/min) | 20 |
Travels - Z Axis Rapid Traverse (m/min) | 24 |
Tool storage capacity
Machining center - No. of tool station | 12 |
---|
Capacity
Chuck size (mm) | 305 |
---|---|
Max. Turning Diameter (mm) | 420 |
Max. Turning Length (mm) | 400 |
Bar Capacity (mm) | n/a |
Main spindle
Main Spindle Max. Speed | 3000 |
---|---|
Main Spindle Max. Power | 26 |
Main Spindle Max. Torque | 863 |
Tool Taper (ISO) | BMT 65P |
Turret
Rotary Tool (r/min) | 4000 |
---|---|
Turret - No. of tool station | 12 |
Dimensions
Length (mm) | 1475 |
---|---|
Height (mm) | 3210 |
Width (mm) | 2075 |
Weight (kg) | 6000 |
Name | Download | File type | |
---|---|---|---|
|
PUMA_V400-2SP.pdf | 2185 KB | |
|
TOOLING SYSTEM-PUMA-V-400.pdf | 195 KB |
Series delivery and installation
The project team manages the entire process, including delivery, installation, and commissioning of the machine, ensuring a seamless project flow. The project team ensures coordination and communication between the project's parties, including the customer, Duroc Machine Tool, and any third-party subcontractors. |
